VOC Monitor & Controller

VOC Monitor & Controller

We offers advance semi conductor based VOC monitor and controllers, which is reliable, efficient and cost effective. VOC can be monitored at Duct, plenum or space mounting for providing total flexibility to suit all applications. The Sensor can continuously track the indoor VOC and odor, and this signal is then delivered to the Central Controller. This helps in the necessary control to dynamically modulate the Ozone output from Duct mounted Units via Variable Load Controller in order to eliminate VOC, odor and smoke.

These sensors are suitable to detect multiple VOCs present in the indoor environment and deliver the signals based on the TVOC. It provides a 0 to 5 VDC Analog signal for interface BMS. The VOC sensor and controller is fully factory wired, which is assembled and field wiring is limited to only input and output connections.

Features

Real time monitoring of TVOCs in the Indoor environment
Advanced sensor with gas sensitive semiconductor (GSS) technology
High accuracy active sampling
Sensor and controller are rated for continuous operation
Provides 0 – 5 V Analog signal
232 communication interface
Robust, reliable and easy to install
Low maintenance

Specifications

Sensor is suitable for mounting in space, duct, plenum, or process chamber
It can be provided with air aspiration enclosure
Sampling air will be aspirated to the enclosure and released
The VOC Sensor is capable of detecting broad range of commonly occurring VOC in indoor applications
Each gas sensed is related by the sensor to its corresponding concentration value to isobutylene
The Sensor is factory calibrated to Isobutylene gas 100 PPM for full span and controlled clean air for zero span
The sensor is provided with digital display
In the event of power failure, or if the system is turned off, the Sensor will retain the pre set sensitivity
The Sensor is suitable for operation in air stream of RH 45% to 65%

Instrument	VOC Monitor & Controller
Instrument	VOC Monitor & Controller
Make	OZ-AIR®
Gas detection	VOC
Options Available	Wall Mounted / Duct Mounted
Sensor	Built-in
Type	Gas Sensitive Semiconductor (GSS)
Meter Range	0 - 500 ppm
Least Count	1 PPM
Accuracy	<+ 10%
Display	LCD / LED Display
Relay Set Point	User adjustable
Rate of Measurement	Continuous
Alarm Setting	Settable Throughout The Range
Operating Temperature	-5^oC to 40^oC
Operating relative humidity	5% to 95% non condonsating
Digital Output	RS 232 (optional)
Analog Output	0 - 5 VDC
Relay Output	24 V; 5A (MAX), 220 V AC, 2 Amp
Power Supply	11 - 24 VDC
